13474-30A/13474-45A/13474-70A/13474-80A/13474-100A/13474-150A
Movable 12/24V Battery Charger
Movable 12/24V Battery Charger is designed for economy-minded do-it-yourselfer.It is heavy-Duty, powerful, and durable for professional mechanics and fleet operations for both slow and fast charge applications. The high-output engine start will assist batteries in cranking most engines under severe summer/winter weather conditions.
Quantity
ltem No.
Description
Single-phase, battery charger and starter, on wheels.
For charging lead-acid batteries with 12/24V voltage and starting all kinds of cars,vans, light trucks, tractors and trucks.
Equipped with selector for normal charge, quick charge(boost),quick start, timer for quick charge and ammeter.
Features
Item | 13474-30A | 13474-45A | 13474-70A | 13474-80A | 13474-100A | 13474-150A |
Power voltage (V) | 220V | 220V | 220V | 220V | 220V | 220V |
Frequency(HZ) | 50 | 50 | 50 | 50 | 50 | 50 |
Rated capacity(W) | 460 | 550 | 770 | 950 | 1000 | 1100 |
Charging voltage(V) | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 |
Rated current(A) | 30 | 45 | 70 | 80 | 100 | 150 |
Starting current(A) | 130/200 | 180/300 | 220/400 | 300/500 | 350/600 | 400/700 |
Suitable battery (Ah) | 30-300 | 30-450 | 30-700 | 30-800 | 30-1000 | 40-1500 |
Protection class | IP21S | IP21S | IP21S | IP21S | IP21S | IP21S |
Insulation class | H | H | H | H | H | H |
Dimension (mm) | 600*310*270 | 600*310*270 | 600*310*270 | 670*360*300 | 670*360*300 | 670*360*300 |
Weight (kg) | 17 | 19 | 22 | 24.5 | 27 | 28 |
